FriendlyELEC NanoPi M6V2 RK3588S 8GB LPDDR5 6TOPS AI Single Computer Board

Key features

[CPU and NPU] Powered by Rockchip RK3588S octa-core big.LITTLE CPU (4×Cortex‑A76 @2.4GHz and 4×Cortex‑A55 @1.8GHz) with a tri‑core 6 TOPS NPU supporting INT4/INT8/INT16/FP16. This combination delivers YOLOv5s inference at 12ms per frame, supporting AI vision, object tracking, and edge analytics without cloud latency., [Memory and Storage] Includes 8GB LPDDR5‑2400 memory (64‑bit) with approximately 30% higher bandwidth than LPDDR4X, plus a native M.2 2280 NVMe slot (PCIe 2.1 x1) for SSD storage.

Boot from NVMe, eMMC module, or microSD, providing access to large datasets, container images, and multiple operating systems., [Video and Codec] Features HDMI 2.1 output up to 8K@60fps with HDR, hardware decoding for H.265/VP9/AV1 at 8K, and 8K H.264 encoding. Use this board for building 4K/8K media servers, digital signage, or low‑latency streaming boxes, with typical power consumption under 10W., [Camera and GPIO] Dual 4‑lane MIPI‑CSI camera inputs and dual 4‑lane MIPI‑DSI display outputs enable multi‑camera vision and dual‑screen projects.

The 30‑pin GPIO header provides 6×UART, 3×I2C, 4×PWM, and 20×GPIO, alongside Gigabit Ethernet – for robotics, drone controllers, and OS and, [Software] Officially certified as Armbian Platinum (Linux 6.1 LTS) with pre‑built images for Debian 12/13, Ubuntu 22.04/24.04, Android 14, OpenWrt, Proxmox VE 8.2, OMV 8.0, and Alpine. Long‑term kernel updates and comprehensive documentation are provided..

Built with Size: 8GB, Color: Bare Board, Model: NanoPi M6V2.
