FP10000Q/FP20000Q Professional Audio Power Amplifier 2 Ohm Stable 4 Channels Class TD Amp 4x1350W 10000 Watts ON-Semi Live Show

FP10000Q Audio Power Amplifier 4 Channels 4x1350W 10000 Watts For Live Show Professional Disco Dj Audio Speakers Subwoofers

Products Profile:

FP series is a high performance switching power amplifier,each channel with independent adjustable peak output voltage.It built with intelligent protection circuit provides advanced technology.It is good for large-scale performances, venues, business senior entertainment clubs and other places.
Advantage:All the Electronic component are from big brand such as Neutrik connector sanken transistor

Amplifier Suggest match:4pcs Single 15inch or
4pcs Double 15inch professional PA speaker or
2pcs single 15inch full frequency professional PA speaker + 2pcs single 18inch sub woofer

FP10000Q FP10000Q+ FP10000Q POR Technical Parameter：

8Ω stereo power: 4X1350W
4Ω stereo power: 4X2100W
2Ω stereo power: 4X2500W
8Ω bridge power: 2X4200W
4Ω bridge power: 2X5000W
Frequency response (+0/-0.3dB, 1W/8Ω): 20Hz-34KHz
Total harmonic distortion 20 Hz-20 kHz 1W: <0.1%
Signal to noise ratio: >112dB
Channel separation (crosstalk) 1 kHz: >70dB
Input connector: XLR female
Output connector: Speakon socket
Input impedance: 20KΩ balanced
Level adjustment: front panel potentiometer, from negative infinity to 0dB
Cooling method: stepless speed regulation fan, air flow from front to back
Power amplifier protection methods: short circuit, open circuit, DC voltage, overheating, radio frequency, ultra-low frequency protection
Power specification: AC 90-130/190-240V (±10%) 50-60Hz
Chassis size (height*width*length): 88mmX483mm×398mm
Packing size (height*width*length): 180mmX560mm×500mm
Net weight: 12kg
Gross weight: 13.4kg

FP20000q technical parameters

8Ω Stereo Power: 4X2350W
4Ω stereo power: 4X4400W
2Ω stereo power: 4X7000W
8Ω Bridged Power: 8000x2W
4Ω Bridged Power:12000x2W
Frequency response (+0 /-0.3dB, 1W/8Ω): 20Hz-34KHz
THD 20 Hz-20 kHz 1W: <0.1%
SNR:> 112dB
channel separation (crosstalk) 1 kHz:> 70dB
input connector: XLR female
output connectors: Speakon Block
input impedance: 20KΩ balanced
level adjustment: Front panel potentiometer, from minus infinity to 0dB
cooling: variable speed fan, airflow from front to rear
amplifier protection: short circuit, DC voltage, overheating, RF, ultra-low frequency protection

Power Supply:
120VAC60Hz;100VAC50/60Hz;220VAC50Hz;
230-240VAC50Hz.
chassis size (H * W * L): 88mmX483mm × 396mm
packing Size (H * W * L): 180mmX560mm × 500mm

The warranty period is as follows:

Green board FP10000Q/FP20000Q Power Amplifiers - 2 years

The warranty period starts from the date of original purchase. Damage caused by human factors or force majeure is not covered by the warranty.

Terms of Service

During the warranty period, we will be responsible for repairing or replacing any defective or damaged products free of charge.
But this is only for damaged parts, if you want to replace the entire circuit board, you must pay for it.

For those that exceed the service life, we will be responsible for repairs and only charge for the replaced parts.

Shipping Costs
For all valid warranty claims, the user shall bear the shipping costs of sending replacement goods. The user shall bear the shipping costs of returning defective goods.

FAQ

1. Are you a factory or a trading company?

Shenndare Audio Equipment Co., Ltd. is a leading professional audio technology supplier. We are headquartered in Guangzhou, China, and are a manufacturer with many years of export experience. We have won an enviable reputation at home and abroad by continuously providing high-quality products and services.

2. How to ship to my country and how long does it take?
It depends on the order quantity and the shipping method, express and sea shipping are optional.
For small orders, we can ship within 3 days after receiving the payment.
For large orders, we can ship within 7 days after receiving the deposit.
Please contact us for more details :)

3. Can I make products with my own logo?
1>.Yes, we can provide you with OEM service, print your logo on the product. After confirming the order, please provide a picture of your logo.
2>. For the logo on the amplifier, screen printing logo is free.

4. I have my own ideas for the products, can you help to produce my own products?
Of course, we can provide ODM service. Please tell us your ideas and needs, our experienced engineers will customize and develop equipment for you. Without your authorization, we will not tell others that we are your supplier, nor sell your products with our own brand.

Shipping:

The shipping time is 24-48 hours after the payment is cleared.

Except for DHL/FeDEX/UPS, which takes about 7-10 days, others take 18-60 days.

(25-45 days for Brazil and about 7 to 20 days for South American countries.)

If you still haven't received the goods within 30 days, please contact us and we will try our best to check and provide assistance.

-We generally ship according to the logistics method selected by the customer.

-For special countries/regions, we will send a special line to facilitate customs clearance for customers.

*Taiwan Province* Taiwan special line will take about 10 days with the best service time.

Important reminder:

Important Notice!! Import duties are borne by the buyer.

According to the customs laws of that country, all imported goods are subject to customs duties. As per AliExpress rules, the buyer is obligated to clear customs and pay these duties.

Feedback:

Your satisfaction is our motivation. Please show the product pictures and leave us a 5-star praise,

Thank you again for your attention.
